Country of Origin
United States
Shipping Weight
0.02 pounds
Manufacturer P/N
MS27640-4
Schedule B Code
8482.10.5068
Ship Dimensions
3 x 3 x 1 inches
Bore Diameter: 0.2500 Inches Nominal Overall Outside Diameter: 0.9014 Inches Nominal Lubrication Material: Grease Outer Ring Width: 0.3350 Inches Nominal Inner Ring Width: 0.4840 Inches Nominal Seal Quantity: 2 Bearing Seal Type: Contact Load Direction: Radial Standard Tolerance Designation: Afbma Std Tolerance For Airframe Ball Bearings Special Features: 80 Pct. Full Of Mil-G-81322,Internal Radial Clearance 0.0004 In. Min,0.0010 In. Max,Heat Treat Rings And Balls To Rockwell C 60 To 66 And Stabilized For Operation At 250 Deg. F,Radial And Lateral Eccentricity Inner Ring 0.0010 In. Outerring 0.0016 In. Lubrication Material Document And Classification: Mil-G-81322 Mil Spec Single Material Response Material: Steel Comp E52100 Outer Ring Material: Plastic Polytetrafluoroethylene Seal Material: Steel Corrosion Resisting Retainer Material: Steel Comp E51100 Ball Or Steel Comp E52100 Ball Material: Steel Comp E52100 Inner Ring Material Document And Classification: 66 Fed Std All Material Responses Ball Material Document And Classification: 66 Fed Std Single Material Response Inner Ring Material Document And Classification: 66 Fed Std Single Material Response Outer Ring Material Document And Classification: Ams 3652 Assn Std Single Material Response Seal Or Ams 3666 Assn Std Single Material Response Seal Surface Treatment: Cadmium Exposed Surfaces As Mounted Surface Treatment Document And Classification: Qq-P-416,Ty 1,Cl 2 Fed Spec Single Treatment Response Exposed Surfaces As Mounted Style Designator: Single Row Inner Ring Extended Both Sides
