Hysol® EA 934NA™ cures at 25ºC / 77ºF, possesses superior strength of 149ºC / 300ºF. Ideal for potting, filling, fairing and shim applications.
Mixing - This product requires mixing two components together just prior to application to the parts to be bonded. Complete mixing is necessary. The temperature of the separate components prior to mixing is not critical, but should be close to room temperature (77°F/25°C).
Mix Ratio By Weight: Part A - 100 / Part B - 33
Pot Life (450 g mass) 40 minutes @ 77°F/25°C Method - ASTM D2471 in water bath.
Application
Mixing - Combine Part A and Part B in the correct ratio and mix thoroughly. THIS IS IMPORTANT! Heat buildup during or after mixing is normal. Do not mix quantities greater than 1 pound as dangerous heat buildup can occur causing uncontrolled decomposition of the mixed adhesive. TOXIC FUMES CAN OCCUR, RESULTING IN PERSONAL INJURY. Mixing smaller quantities will minimize the heat buildup.
Applying - Bonding surfaces should be clean, dry and properly prepared. For optimum surface preparation consult the Hysol Surface Preparation Guide. The bonded parts should be held in contact until the adhesive is set. Handling strength for this adhesive will occur in 8 hours @ 77°F/25°C, after which the support tooling or pressure used during cure may be removed. (Alternates are: 20 minutes @ 140°F/60°C, or 1 minute @ 205°F/96°C.) Since full bond strength has not yet been attained, load application should be small at this time.
Curing - This adhesive may be cured for 5 to 7 days @ 77°F/25°C to achieve normal performance. Accelerated cures up to 200°F/93°C (for small masses only) may be used as an alternative. For example, 1 hour @ 200°F/93°C will give complete cure.
Cleanup - It is important to remove excess adhesive from the work area and application equipment before it hardens. Denatured alcohol and many common industrial solvents are suitable for removing uncured adhesive. Consult your supplier's information pertaining to the safe and proper use of solvents.
