David Clark 09168P-35 Model M-77 Unamplified Electret Microphone
Click To Enlarge
David Clark 09168P-35 Model M-77 Unamplified Electret MicrophoneDavid Clark 09168P-35 Model M-77 Unamplified Electret Microphone

David Clark 09168P-35 Model M-77 Unamplified Electret Microphone

Part#: 09168P-35
Our Price: $37.50
Loading Item Availability: If this message doesn't go away please enable Javascript to see product Availability!
International Orders
Quantity:
$15.00Add the Manufacturer's Certification:
Manufacturing
Country of Origin: USA
Material Safety Information
Not Applicable for this Product
Bulk Shop & Save
1 - 5$37.50 ea.
6 - 11$37.15 ea.
12+$36.69 ea.


The David Clark M-77 unamplified electret microphone features impressive noise-cancelling properties to improve use in your cockpit. Install this microphone in circuits that supply a DC bias voltage. The David Clark M-77 weighs just six ounces, a lightweight accessory that will keep your headset comfortable during flight. Find a replacement microphone or upgrade your current model with this noise-cancelling device. The M-77 is designed to perform in 4.7K AC load. Our David Clark electret microphone mates with U-173/U connector to deliver clear communication in your cockpit.

Enjoy this lightweight microphone with your David Clark headset. The affordable 09168P-35 will enhance your headset use. Replace your damaged microphone with the David Clark M-77. This product is an affordable way to improve your headset without breaking your budget. At SkyGeek, find budget-friendly accessories that will make your cockpit more comfortable and efficient. Our selection of headsets and headset products are perfect gifts for any aviator.


Product Details
UOM : Each
Ship Dimensions : 4 x 5 x 3 inches
Shipping Weight : 0.1 pounds
Manufacturer P/N : 09168P-35
UPC : 700736684061
EAN : 0700736684061
ECCN : EAR99
Schedule B Code : 8518.90.3000
Disclaimer: While reasonable efforts have been made to ensure all information on this website is accurate, SkyGeek.com and Styles Logistics, Inc. do not assume responsibility for any errors or omissions. All specifications, illustrations, data and prices are subject to change without notice.
Specifications
  • Microphone is designed to function in 4.7K AC load as shown.
  • Sensitivity:22mv +6/-2 dB at 105 dB SPL (Ref. .002 microbar) at 1 KHz into Circuit below
  • Frequency Response: See typical response
  • Generating Element: Electret condenser
  • Polar Pattern: Bidirectional Noise Cancelling
  • Connector: Mates with U-173/U Connector
  • Weight: 6 grams
  • Power Requirements: Polarized Operation, nominally 240 ua at 7.5vdc. 5-15 supply range
