Home Owner Shop Shop Supplies Hardware Gaskets Engine GasketsSociety of Automotive Engineers AS3491-01 Vacuum Pump Gasket

Society of Automotive Engineers AS3491-01 Vacuum Pump Gasket

Availability: Ready to Ship in 3 Business Days

International Orders

Part#: AS3491-01

by Kapco-Valtec

Review this Item

Description
Reviews
Alt. Part Numbers
Customer Q & A

Kapco-Valtec non-asbestos fiber gasket.

Overall Rating for Society of Automotive Engineers AS3491-01 Vacuum Pump Gasket

(no reviews)

Be the first to rate and review this item

Lycoming Part Number: 8313
Rolls-Royce Part Number: 23052954
Superior Part Number: SL8313
ECI Part Number: AE9134
Teledyne Continental Part Number: 653487
Generic Part Number: AN4045-1, MS9134-01

Your question might already be answered below, wouldn't that be a time saver!
If your question has not been answered below please click the "Ask a Question" button below, fill out the form, and one of our Geeks will answer it as quickly as possible.

Note: Our Geeks are available Monday-Friday 9AM to 5PM (EST) normal business days, to respond to your questions.

Product Details

Shipping Weight : 0.1 pounds

Manufacturer P/N : AS3491-01

NSN : 5330-01-453-0554

Schedule B Code : 8803300010

Alt. P/Ns : AS3491, MS3491-01, 3049T11P01

Specifications

Aperture Diameter: Minimum: 1.552"; Maximum: 1.572"
Bolt Hole Diameter: Minimum: 0.271"; Maximum: 0.291"
Cross Section Shape: F33 Solid Single or Composition Nonmetallic Material
Cross Section Thickness: Minimum: 0.014"; Maximum: 0.021"
Material: Fiber Nonasbestos Overall
Material Document and Classification: A50TF268 Class A CAGEC 99207 MFR REF Single Material Response Overall
MFG Part Number: AS3491-01
Outside Corner Radius: Minimum: 0.271"; Maximum: 0.291"
Overall Length: Minimum: 2.428"; Maximum: 2.448"
Overall Width: Minimum: 2.428"; Maximum: 2.448"
